Right-angle thermocouple is applicable to high temperature production field. On occasions that gasesdo harm to connection head or thermocouple can not be installed horizontally or vertically, right-anglethermocouple is also suitable. Process connection: movable flange or movable compression thread.
Indoor thermometer is applicable to cold storage, oasthouse, thermostatic chamber, air-conditioned roomcommunications room, warehouse and other indoor or outdoor room which needs to control measurementIt measures accurately and is easy to install.
The casing or component of the corrosion-resistant thermocouple (resistance) is wrapped in polytetrafluoroethylene, known as the "king of plastics." It is resistant to the corrosion of most acids, alkalis, and organic substances. With a temperature measurement range of <200°C, it can replace expensive metal protective tubes such as high-nickel alloys, titanium, and tantalum. It has advantages such as low cost and ease of processing.
The thermocouple with heat dissipation function at the cold end is a heat sink in the middle of the sleeve insertion section and the junction box part to reduce the temperature in the junction box.
Surge protector and temperature transmitter are installed in the connection head of lightning-protectionand explosion- proof integrated thermocouple or RTD, $urge protector prevents product from damageby lightning or transient overvoltage. This type thermocouple or RTD is safe to use in thunderstorm area.
Integrated temperature transmitters, also called integrated thermocouples and RTDs, output standard 4-20mA current,linear with temperature. With temperature transmitter installed in the connection head of thermocouple or RTD, integratedtemperature transmitter communicates with distributed control system via HART or FF bus protocol. Integrated temperature transmitters can be divided into with on- site display type and without on- site display.We offer various imported and domestic brands of temperature transmitters, such as Rosemount,PR, Honeywell, Yokogawa, E+H, ABB.
Thermowells installed in pipelines generate vorices due to the high-speed flow of the medium impacting the casingWhen the wake frequency and natural frequency are the same, they will produceResonance may cause the fracture oithe casing. in response to this siluation, our campany has designed two types of reinforced anli vibralion and anli faliquesleeves, one of which is at temperatureA reinforcing nall is installed on the outer side of the casing, and when strong fluidgenerates flow, the vibration amplitude of the casing of the temperature sensor will decrease, thus reducing the vibrationfrequencyAnd reduce the faigue ofthe casing. The second step is to process a spiral shaped convex strip on the casingwhich can cut of the liquid flow and prevent the casing from forming in the mediumResonance, this structure does notreguire thickening the outer diameter of the casing or setting a reinforcing ring, both of which can extend the service ifeof the casing. Calculation of casing freauencylndustry standard ASME PTC 19.3 TW-2016.
There are double cuting ferrules between upper and thermowell, making double-layer leakage-proof by tighteningthe screws and nuts. immersed in media, once thermowell of thermocouples and RTDs break, media will come outalong the thermocouples and RTDs lo cause damage.
